  • 'PWRCORE 20™' battery system
  • Orbital action
  • Variable speed
Available in Stores
3440 CA

'Compact brushless' cordless jigsaw

KEEPCOOL™

KEEPCOOL™

Our patented ‘KEEPCOOL™’ technology prevents batteries from overheating and improves battery performance.

View Innovation
ACTIVCELL™

ACTIVCELL™

Our intelligent ACTIVCELL™ technology continuously monitors the voltage, temperature and current of the battery. Transmitting this information to the tool in real-time, it helps extract the right amount of energy from the battery for the job.

View Innovation
PWRCORE 20

PWRCORE 20

Do you have big jobs planned? Rest assured, SKIL has the solution. Our ‘PWRCORE 20™’ battery system and smart, intuitive tools that are packed with innovation ensure you have the right power to get any job done.

View Innovation

Product Description

Brushless cordless jigsaw with extremely compact barrel grip design
The ‘20V Max’ 3440 cordless jigsaw is part of SKIL’s compact brushless range. These tools are extremely compact and offer a combination of high performance, durability and an unmatched level of convenience. Like all other SKIL ‘20V Max’ cordless tools, this model is powered by the industry-leading advanced ‘PWRCORE 20™’ battery and charger technology. Our SKIL 3440 brushless cordless jigsaw is perfect for accurate sawing of curved and straight cuts. The extremely compact and lightweight barrel grip design ensures optimal control and guidance, which is even extra beneficial when working with the jigsaw held upside down. The digital brushless motor delivers more power, more efficiency and a 10x longer lifetime than a comparable brushed motor. Good visibility of your work is assured, thanks to the unique ‘360 ° LED’ light that illuminates the sawline without shadows. With the pre-select variable-speed control you can use this jigsaw for the best results in various materials. This jigsaw even has a special ‘Auto Speed’ setting that ensures a controlled start. The tool runs up to maximum speed automatically and only after the actual sawing has already started. With the blade eject function there is no need to touch hot blades when changing them, and the electric brake assures greater comfort and allows quicker work. You can easily adjust the highly durable aluminium footplate for making bevel cuts. The SKIL 3440 CA is supplied with one saw blade for wood, one saw blade for metal, one blade for sawing curves and a vacuum cleaner adapter. The battery and charger aren't included.

‘PWRCORE 20™’ industry-leading battery technology to power all SKIL '20V Max' tools
The ‘PWRCORE 20™’ system consists of industry-leading advanced battery and charger technology, plus innovative features you won’t find anywhere else, such as our patented ‘KEEPCOOL™’ battery cooling technology which increases the runtime by up to 25% and doubles the battery lifetime. Whereas the patented ‘ACTIVCELL™’ technology safeguards a maximum performance and optimal battery protection. The ‘PWRCORE 20™’ batteries and chargers are 100% compatible and interchangeable with all SKIL ‘PWRCORE 20™’ power tools and garden tools for ultimate flexibility.

Read More

Specifications

Technical

Sawing capacity in aluminium 20MMT
Sawing capacity in wood 135MMT
Sawing capacity in metal 10MMT
Number of batteries 0
Battery type
Lithium-Ion
Net weight excl. battery
1.5 kg
Blade speed 800-3500s.p.m.
Orbital settings 0,1,2,3
Stroke length 23MMT
Voltage Max
20V Max
Read 4 More

Noise and Vibration Levels

Vibration level (cutting metal) 6.08MSK
Vibration level (cutting wood) 7.68MSK
Sound power 98 dB
Sound pressure 87 dB
Uncertainty noise power (K) 32N
Uncertainty Vibration (K) 1.5 m/s²

Executions

advanced Performance
'Compact brushless' cordless jigsaw

3440 JA 'Compact brushless' cordless jigsaw

  • 'PWRCORE 20™' battery system
  • Orbital action
  • Variable speed
  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getReviews, 16.45ms
  • REVIEWS, PRODUCT
  • bvseo-msg: HTTP status code of 404 was returned; HTTP status code of 404 was returned;

Documents

Manuals

Leave your email address to download the documents. Don't worry we won't send you unsolicited emails, just a confirmation.

SKIL 3440 CA Instruction Manual
